Parameter

Details

Model

SS-NC50L5CP-QMPX-VF-M8(4K)

Make

SECURUS

Image Sensor

1/2.7“ Sony STARVIS CMOS Sensor

Image Pixels

3840x2160 (8.0MP), 2880x1616 (5.0MP), 2560x1440 (4.0MP), 2304x1296 (3.0MP), 1920x1080 (2.0MP)

Minimum Illumination

Color: 0.0001Lux@F1.2;

B/W: 0.0001Lux@F1.2, AGC ON, 0Lux with IR

Day/Night

Auto (ICR) / Color / Black & White

WDR (Wide Dynamic Range)

Supported (≤140db)

IR LED

4 Pcs High Power LED Array

IR Distance

30 ~ 100 Meters

Shutter Type

Manual/Auto

Shutter Speed

1/25s ~ 1/100000s

Lens Mount

2.8mm~12.0mm/2.7mm~13.55mm/

6.0mm~22.0mm/5.0mm~50mm

Lens Type

Motorized Auto-Focus Lens

Network Interface

10/100 MBPS RJ45 Connector

Network Protocol

HTTP, TCP, ARP, RTSP, RTP, UDP, RTCP, SMTP, FTP, DHCP, DNS, DDNS, PPPoE, IPv4/v6, SNMP, QoS, UPnP, NTP

Video Encoding

H.265AI/H.265+/H.265/H.264+/H.264

Video Bitrate

128kbps ~ 8Mbps

Video Streams

Triple Stream

Video Stream Resolution

Main Stream: 3840 x 2160 @15FPS;

2880 x 1616 @25/30FPS; 2560 x 1440 @25/30FPS; 1920 x 1080 @25/30 FPS

Sub Stream 1: 800 x 448 @25/30FPS

Digital Zoom

Supported (Max: 16X)

Audio Input

Yes; 1Ch; 2Vp-p 1kᲲ Impedance (Optional)

Audio Output

Yes; 1Ch; 16Ჲ Impedance (Optional)

Audio Compression

G.711 (Optional)

Image Setup

Mirror Image/Reverse/Color Settings

Alarm Trigger

Motion detection, HDD full, HDD error, IP Address conflict, Illegale Login, Video Loss

Intelligent AI Feature

Human Detection, Face Detection, Vehicle Detection, Active Deterrence,

Line Crossing, Trip Wire

Operation Temperature

-10°C ~ +65°C

Operation Humidity

0% ~ 90%

Power Supply

DC12V, PoE (IEEE802.3af)(Class 0)

Power Consumption

≤3.6W without IR; ≤8W with IR

Multiple Browsers

Supports (Chrome, Mozilla, Edge, Opera)

SD Card

Supported (Upto 512 GB) (Optional)

ONVIF

ONVIF Conformant

Housing Material

Aluminum + ABS

Dimensions

180mm x 70mm x 70mm

Weight

≤1.0 KGs

Ingress Protection

IP67

Certifications

CE, FCC, RoHS, BIS
