Parameter

Details

Model

SS-NC50L5CP-EC-VF-M2

Make

SECURUS

Image Sensor

1/2.7“ Progressive Scan CMOS

Image Pixels

2304 x 1296 (3.0MP), 1920 x 1080(2.0MP)

Minimum Illumination

Color: 0.005Lux@F1.2; B/W: 0.001Lux@F1.2

Day/Night

Auto (ICR) / Color / Black & White

WDR (Wide Dynamic Range)

≤140db

S/N Ratio

≥50db

IR LED

4Pcs High Power LED Array

IR Distance

30 ~ 100 Meters

Shutter Type

Manual/Auto

Shutter Speed

1/25s ~ 1/100000s

Lens Mount

2.8mm~12.0mm/2.7mm~13.55mm/

6.0mm~22.0mm/5.0mm~50mm

Motorized Auto-Focus Lens

SD Card

Supported (Max: 512GB) (Optional)

Network Interface

10/100 MBPS RJ45 Connector

Network Protocol

HTTP, TCP, ARP, RTSP, RTP, UDP, RTCP, SMTP, FTP, DHCP, DNS, DDNS, PPPoE, IPv4/v6, SNMP, QoS, UPnP, NTP

Video Encoding

H.265AI/H.265+/H.265/H.264+/H.264

Video Bitrate

128kbps ~ 8Mbps

Video Streams

Triple Stream

Video Stream Resolution

Max : 2304 x 1296; 1920 x 1080; 720 x 576; 25/30 FPS

Digital Zoom

Supported (Max: 16X)

Audio Input

Yes; 1Ch; 2Vp-p 1kᲲ Impedence (Optional)

Audio Output

Yes; 1Ch; 16Ჲ Impedence (Optional)

Audio Compression

G.711A (Optional)

Image Setup

Mirror Image/Reverse/Color Settings

Alarm

Yes (Optional)

Intelligent AI Feature

Face Detection, Human Detection,

Active Deterrence, Line Crossing,

TripWire

Operation Temperature

-10°C ~ +65°C

Operation Humidity

0% ~ 90%

Power Supply

DC12V, PoE (IEEE802.3af)(Class 0)

Power Consumption

≤3.6W without IR; ≤8W with IR

Multiple Browsers

Supports (Chrome, Mozilla, Edge, Opera)

Housing Material

Aluminum + ABS

Dimensions

180mm x 70mm x 70mm

Weight

≤0.5 KGs

Ingress Protection

IP67

Certifications

CE, FCC, RoHS, BIS
