Parameter

Details

Model

SS-N8128RV-H16-M5

Operating System

Embedded LINUX

Processor

High Performance 64 Bit Multi-Core Processor

Main Board

Server Special Use Mainboard

Ram

16g

Built-In Disk

Enterprise Hard Disk

Video Management

Default 200 channel Management (Maximum Expansion 10000 Channels) + Up To 128 channel Forwarding (3m Stream)

Management Function

Central Management, Front-End Management, User Rights Management, Storage Management, Registration Management, Alarm Management Stream Media Management.

Display Interface

Vga *1

Usb Interface

Usb *6

Network Interface

2 Gigabit Net Port And 1 IPMI Port

Serial Port

1

HDD Port

16 SATA

Radiator

Server Special Use Radiator

Fan

Server Special Use Fan*4

Led Indicator

Power Indicator Lamp, Hard Disk Indicator Lamp, Net Port Indicator Lamp, Fault Alarm Indicator Lamp

Voltage Input

Ac100~240v ，50~60hz

Power Supply

550w Server Single Power Supply

RAID

Supported RAID 0, 1, 5, 6, 10, 50, 60

Working Temperature

Working：5℃～40℃ Storage：-20℃～70℃

Working Humidity

Working：20%～80%Rh（no Ice, No Condensation) Storage：5%～95%Rh（no Ice, No Condensation）

Dimension(Mm)

550(Width) X 430(Depth) X 88(Height)

Net Weight

About 11kg

Certifications

CE, FCC, RoHS
