Parameter |
Details |
Model |
SS-N8032RV-H8-M5 |
Make |
SECURUS |
User Interface |
Graphic User Interface (GUI) |
Operating System |
Embedded Linux |
Operation Mode |
Preview, Record, Playback, Backup, Network |
Password Security |
Multi-level User Management |
ONVIF |
Support |
Video Input |
32ch 5M/16ch4K/16ch1080P |
HDMI Output |
Supports 2 (Max : 4K) |
VGA Output |
Supports 1 (Max : 1080P) |
CVBS main output |
N.A. |
Audio Input |
1 Ch |
Audio output |
1 Ch, RCA connector |
Display |
1/4/6/8/9/10/13/16/25/32 optional |
Video standard |
PAL/NTSC |
Video compression |
H.265AI/H.265+/H.265/H.264+/H.264 |
Intelligent Functions |
Face Detection, Vehicle Detection, Human Detection, Active Deterrence, Line Crossing, Trip Wire, People Counting |
Video encoding resolution |
12MP; 8MP; 5MP; 4MP; 3MP; 1080P |
Synchronous Playback |
8CH |
Video frame rate |
PAL: 1-25 FPS NTSC: 1-30FPS |
Video bit rate |
1536kbps-3072kbps |
Stream Type |
Video & Audio/Video |
Audio compression |
G.711a |
Recording mode |
Always/Schedule/Alarm/ recording/Motion detection recording |
Video search |
Time/Channel/Event |
Display Zoom |
Live Playback & Mobile |
Audio bit rate |
8—32kbps |
Dual-stream |
Supports |
Mobile Monitoring |
"RMEye Pro" Application for Android And iPhone |
Recording resolution |
32 CH Realtime Recording |
HDD Port |
8 SATA |
HDD Maximum Capacity |
12TB for each Sata connector |
Voice talk |
Support; 1CH BNC line in/1CH RCA Audio out. |
Record mode |
Audio & Video recording simultaneously |
Remote control |
Supports |
Network protocol |
Supports IE/PPPoE/DDNS |
Network bandwidth |
900Mbps |
DDNS Server |
|
Network |
2 RJ45 10M/100M/1000M |
USB Connector |
2 x USB2.0 1 x USB3.0 |
Firmware update |
Support USB update/Network update |
Serial Interface |
RS485, RS232 |
Alarm input |
16 |
Alarm output |
4 |
Intelligent AI Feature |
Face Detection |
Power supply |
ATX |
Operation Temperature |
-10℃--+55℃ |
Operation Humidity |
10%--90% |
Chassis |
Standard 2.0U |
Dimension |
427.5mm (W) × 443mm (L) × 92mm (H) |
Weight(without HDD) |
≤6.0Kg |
Certifications |
CE, FCC, RoHS, BIS |
