Parameter

Details

Model

SS-N08EP-G2-UTL

Make

SECURUS

Network Ports

8 Ethernet Ports : 10/100 Mbps

2 Up-link Ports: 10/100/1000 Mbps

Transmission Distance

8 POE Ethernet Ports :

100 Mtrs @ 100 Mbps; 100 Mtrs @ 10 Mbps

2 Up-link Ports : 100 Meters

Transmission Media

Cat5e/Cat6 Standard UTP Cable

POE Standard

IEEE802.3 af/at Standard

POE Power Supply Method

End-Span Method

POE Power Supply Watt

Each Port ≤30W, Total Power 120W

Network Standard

IEEE802.3, IEEE802.3u, IEEE802.3ab,

IEEE802.3az, IEEE802.3z

Swap Mode

Store & Forward

Data Caching Mechanism

1 M

MAC Address List

2 K

Reset Button

Available

VLAN Switch

Available

Bandwidth

5.6 Gbps

Frames filter and transfer rate

10M port maximum 14,800pps, 100M port maximum 148,800pps

Communication Protocols

IPv4 and IPv6 Compatible

Power Supply Mode

Built-In

Power Consumption

<10W

Working Temperature

0˚C ~ +60˚C

Storage Temperature

-40˚C ~ +70˚C

Humidity

0 ~ 90%

Dimensions (L x W x H)

220mm x 105mm x 28mm

Color (Chasis)

Black

Weight

≤612 Grams

Mean Time Between Failures

(MTBF)

>50000 Hours
